Lowell Observatory Solar Eclipse Experience 2017. This event at Madras High School will include daytime activities and talks by astronomers on Sunday and Monday and night time star gazing on Sunday. If you are planning on being in the Madras area, I encourage you to purchase tickets for this event. In addition to the program of events, your $15 will get you a pair of eclipse glasses, access to a water station, food and beverage vendors, and the air-conditioned auditorium. The eclipse itself will be narrated by solar astronomers. In this post I will describe my contributions to the Lowell event and ideas for you to enhance your total and partial eclipse experience.
Rich Krueger contacted me last year about contributing to the Lowell Observatory Eclipse Event. Rich teaches at Flagstaff Arts and Leadership Academy and is a fellow SOFIA Airborne Astronomy Ambassador. Rich flew on SOFIA with Lowell Observatory Curator, Samantha Thompson. Lowell tapped Rich to help fill out the outstanding program they are preparing for the day before and day of the eclipse. Rich originally wanted me to recreate Eddington's total eclipse observation that confirmed Einstein's Theory of General Relativity. I had read Donald Bruns' article in Sky and Telescope and knew this was beyond my skill and bank account. Even Mr. Bruns is only doing half of the experiment. He plans to use undeflected star positions from the Gaia catalog. Eddington did not have this luxury! I assured Rich I would bring something else that would interest and engage the crowd. Others may try to measure the star field around the eclipsed Sun at the Eclipse Experience, but the deflections are so tiny nothing will be evident that day.
My first thought was to bring the Spacetime Simulator that I use in the viral Gravity Visualized video. I would do demonstrations like the ones in the video plus the new ones I have added. Another idea is to make a bent spacetime game by distributing a bunch of 0.5, 1, and 2 kg masses on the fabric. Place a goal on one side and launch a marble from the other. The marble represents a photon following the geodesic of the warped spacetime. The winner reaches the goal in the longest amount of time. Doing these activities should keep me pretty busy, but I wanted to develop something new too. I also suspect that I won't be the only one bringing a spacetime simulator since so many people have built their own with the help of this DIY video.
My next idea was to make a large convex mirror using a spaceblanket and a kiddie pool. I briefly alluded to this at the end of my post about making concave and convex mirrors with trashcan lids and spaceblankets. I was inspired to create a large convex mirror by the fisheye lens pictures taken in previous total eclipses. They show a 360 degree sunset with a brilliant but small eclipsed sun floating in the twilight. I also remembered the picture of the 1991 total eclipse over Mauna Kea. You can see the eclipsed sun and sky in the reflection of the silvered observatory dome on the left. I wondered what you could see in a large convex mirror placed flat on the ground. Maybe it would give a similar view to the unaided eye in real time.
|From Sky and Telescope 35mm slide set|
|Wolfgang Strickling, 3/9/2016 Eclipse|
I picked up a 45" wading pool from Big 5 Sporting Goods. I cut the presta valve from a bicycle tube, put it through a hole in the side of the pool, and sealed it with silicone adhesive. I used the top of the pool to mark a circle on the spaceblanket and cut it out. I used strapping tape to attach the spaceblanket over the top and started inflating it. It worked great, here is the result:
|45" Spaceblanket/Kiddie Pool convex mirror|
string to measure the mirror while inflating it. When the string showed the spaceblanket was not stretching anymore, I stopped inflating it. The larger mirror gave a satisfying view inside my classroom and outside in the full sun. I can't wait to see what it looks like during a total eclipse of the Sun. If I had to do it again I would stick to the smaller version. The large mirror barely fits into my Honda Odyssey and the oversize spaceblanket is not as reflective as the regular size. I may even make another smaller version to take instead of the large one since I will need room to transport a lot of equipment and gear to Madras.
I have been observing the Sun, solar eclipses, and transits with students for many years. As a result I have a good collection of solar observation equipment. The pièce de résistance is a Coronado Solarmax 70mm H-Alpha telescope (discontinued). I purchased this many years ago with a grant from the Home and School Club, Los Gatos High's version of the PTA. I made sure to come to one of their meetings after getting the telescope to show them the prominences, filaments, plages, and supergranules that students would get to see. If you want to get something similar for your school, the Coronado Personal Solar Telescope is very capable and more affordable at $599. I will bring a Meade 10" SCT with solar filter, 20x80 binoculars with solar filters, a box of eclipse glasses, and an 80mm refractor with a Sun Funnel. What is a Sun Funnel? That is what I thought when I first came across this solar observing aid. It is a safer way to do eyepiece projection, pointing an unfiltered refractor at the Sun and aiming the eyepiece toward a screen. Once focused, a nice large image of the Sun shows up on the screen. I have done this many times but always worried someone would look in the eyepiece and injure themselves. The Sun Funnel is placed over the eyepiece and projects the image on the back of a screen fastened to the other end. I followed the very clear instructions and made one in about 15 minutes after assembling the materials. If you have access to a small refractor, I highly recommend you build one. Small refractors can be purchased for less than $100 and work well with the Sun Funnel as long as you use an eyepiece and star diagonal that are made of metal, no plastic.
[Dean adds: for the May, 2012 eclipse, I made "eclipse portraiture" an extra credit project. My own "before and during" has been published in a few places.]
Another way to reveal the partial phases of the eclipse is to reflect a solar image from a mirror. I use this to bring the Sun into the classroom. I use a front-surfaced mirror to get a crisper image. I mask off the surface of the mirror except for a hole made with a paper punch. This produces a brighter image than a pinhole so you can project it over a longer distance to create a larger image. You still need to project the image into a shaded location to make the it easily visible. I am going to place a sheet of white paper in a box for the eclipse.
|Solar Spectrum using Red Tide spectrometer with Logger Pro|
Projecting a solar image is useful even if there isn't an eclipse going on. Imagine a solar image projected through your classroom door onto your whiteboard for the whole class to see. Large sunspots should be visible. After a little time, students will notice that the solar image moves. Propose the idea of determining how much time it would take the solar image to move all the way around, back to where it started. Draw a circle around the image and time how long it takes to move completely out of it. How many images would it take to complete one circle? The Sun's apparent size is about 0.5 degrees so 360/0.5 = 720. Multiply the time measured by 720, this should give about 24 hours. How about that! You can improve your answer by calculating the exact apparent angular size of the Sun for the current distance to the Sun on the day you do this activity. I also use a spectrometer to display the solar spectrum using the projected solar image as the light source.
As you can see, I will be very busy for the total eclipse on August 21st. Even if you can't make it under the path of totality, I hope you will be busy sharing this event with your students, family, and friends. I have used this post to give you some ideas to enhance the experience. I urge you to use them in your classroom beyond the Great American Eclipse day. The concluding post of this series will describe my experience in Madras. It will be interesting to contrast it to my first total eclipse experience that I described in Part 1 of this series. I also will be posting live on Twitter @kilroi22.
